AGACAD CONCRETE SOLUTIONS
AGACAD is the best Revit extension for managing the creation of Concrete and Precast Concrete structures. Below is a list of the main solutions available to empower your business design to manufacturing performance.
Concrete Specialty Solutions
Precast concrete detailing software for modeling prefabricated buildings in Revit®
AGACAD Precast Concrete software for Revit streamlines your 3D design process by automating the modeling, detailing, and documentation stages.
Efficiently model floor slabs, wall panels, beams, and columns. Insert connection details by the batch-load and place reinforcement. By leveraging BIM, all your shop drawings are automatically generated from the 3D model. And if any changes are made to the project, enjoy the benefits of running full-project, real-time updates on the Revit platform. The end result? Quality production and accurate assembly on site.
BIM software for placing steel reinforcement bars in solid & multi-layer concrete walls in Revit® models.
AGACAD Wall Reinforcement is a feature of our Precast Concrete design software for Revit that lets you create, update and modify reinforcement for solid, double, and sandwich walls in Revit. It recognizes the shape of the wall panel and distributes the main reinforcement and additional reinforcement for the wall perimeter and openings. Using Wall Reinforcement, you can place vertical, horizontal or diagonal rebar, edge reinforcement, and U/O-bar.
Rebar detailing tools for automated reinforcement, shop drawings and CAM-file-generation for precast concrete beams in Revit®
AGACAD Beam Reinforcement is a feature of our Precast Concrete structural design software for Autodesk® Revit® that lets you create, update and modify reinforcement for rectangular, L and inverted T beam sections in Revit models.
Rebar detailing tools for automated precast design and detailing of reinforced concrete columns in Revit® models
AGACAD Column Reinforcement is a feature of our Precast Concrete structural design software for Revit that lets you create, update, and modify reinforcement for columns with corbels in Revit models.
Included Core Technologies
AGACAD Smart Connections instantly adds any number of face-based Revit families – which adapt to host-element changes – throughout BIM models. Easily set up rules to insert or adjust details based on gravity point, depth, adjacent elements, and more.
It saves many hours per project, especially for structural engineers.
AGACAD Smart Assemblies speeds up production of assembly documentation in Revit®. This plugin creates selected views, rules-based dimensions, and assembly sheets you need for combinations of structural and architectural elements.
AGACAD Smart Views speeds up the creation of views and dimensions for selected elements in Revit®. Not only does the plugin generate the number of views that you set in the configurations, but it also automatically places dimensions in those views according to your predefined rules.
