AGACAD Smart Assemblies Solution

AGACAD Smart Assemblies.

Select your license type, quantity, and training requirements.

SAVE 10% with a 3-Year Subscription!

Purchase for a single station or for a complete design team!

See the Description tab below for more product information.

From: $984.00 + Tax

Generate shop drawings in Revit® automatically with corresponding views & dimensions

For metal, wood, precast concrete & other structural projects

Smart Assemblies speeds up production of assembly documentation in Revit®. This plugin creates selected views, rules-based dimensions, and assembly sheets you need for combinations of structural and architectural elements.

Smart Assemblies overcomes limitations in Revit functionality so that manufacturers and on-site personnel can generate shop drawings easily.

Smart Assemblies provides a powerful set of functions for preparing shop drawings:
  • An assembly combines multiple hosted or nested concrete and steel elements into a single entity that can be dimensioned, scheduled, tagged, and isolated to create assembly views and sheets.
  • Automatically rotate assembly origin for walls, beams, columns etc.
  • Control / manage / update changes in assemblies with Dynamic Smart Assemblies Update.
  • Assembly views and sheets are automatically generated by the current Shop Drawing Configuration.
  • Schedules and sheets are grouped and displayed in a separate tabs in Shop Drawing Configurations dialog.
  • Flipped version of default Revit views can be created at once using Shop Drawing Configurations window of Smart Assemblies.
  • Creates assemblies and views by manually defined Configuration Name in the shared parameter – Smart Assembly Configuration.
  • Possibility to find/select/isolate Primary and Secondary Assemblies.
